JRC M1568BS Used Working Radar Magnetron

Product Overview

The JRC M1568BS is a high-performance X-Band Marine Radar Magnetron designed for use in professional maritime navigation systems. Engineered by Japan Radio Co., Ltd. (JRC), this magnetron is a critical component for transmitting the high-power microwave pulses required for surface search and object detection. It operates at a fixed frequency within the 9.4 GHz range, delivering a peak power output of 25 kW. As a Used Working unit, this magnetron has been verified to maintain the stable oscillation and spectral purity necessary for high-resolution radar imaging in all weather conditions.

Key Features

• High Peak Power: Delivers a reliable 25 kW peak output, providing the long-range detection capabilities essential for ocean-going vessels.
• X-Band Precision: Operates at a nominal frequency of 9410 MHz, offering superior target discrimination and resolution for coastal and open-sea navigation.
• Integrated Magnet Design: Features a compact, integral magnet structure that ensures stable magnetic field distribution for consistent RF performance.
• Maritime Durability: Built to withstand the extreme vibration, humidity, and temperature fluctuations characteristic of marine environments.
• Low Anode Voltage Requirement: Optimized for efficiency within JRC radar power supply units, reducing thermal stress on the modulator components.
• No. 10 Waveguide Compatibility: Equipped with a standard flange interface for direct mounting to the radar's transmitter waveguide system.

Item Condition (Used Working)

• Functional Status: Used Working. This magnetron has been professionally tested. The heater filament is intact, and the unit has been verified for correct anode current and stable RF output.
• Physical State: Good industrial condition. The mounting flange is clean, and the output window is free of arcing or carbon deposits.
• Technical Integrity: Verified to meet the minimum power threshold for operational radar systems. It has been handled with strict mechanical care to protect the internal vacuum envelope.
• Note: Professional installation by a certified marine electronics technician is required. CAUTION: Magnetrons contain high-strength magnets; keep away from heart pacemakers, magnetic storage media, and sensitive navigational instruments.

Package Includes

1. 1 x JRC M1568BS X-Band Marine Radar Magnetron
